1030250 | LAPP
PVC data cable, 25-wire, 0.34 mm², AWG 22, black, 1030250
Order No.: 33P7269
EAN: 4064727114057
MPN:
1030250
UNITRONIC LiYY 25x0,34 BK
Series: UNITRONIC LiYY BK
Unit Price (€ / mtr.)
4.522 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 1030250, LAPP
The 1030250 is a data cable for low frequency applications. The cable is designed for fixed installation and for conditional flexible use. It can be used in dry and damp rooms and also outdoors. The cable is used for example in computer systems, instrumentation technology, office equipment and balances.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Outer diameter | 11.2 mm | |
| AWG cross-section | AWG 22 | |
| Number of cores | 25 | |
| Core insulation material | PVC | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Halogen free | No | |
| Material | PVC | |
| Cable material | copper, bright | |
| Version | data cable | |
| Shielding | unshielded | |
| Cable cross-section | 0.34 mm² | |
| Temperature range (active) | -5 °C to 70 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | BG |
| Customs tariff number | 85444993 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
