22595 | HELUKABEL
PUR control line MULTIFLEX 512-C-PUR 4 G 1.0 mm², AWG 18, shielded, gray, 22595
Unit Price (€ / mtr.)
9.044 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 22595, HELUKABEL
The 22595 is a specially screened drag chain cable that offers applications possibilities in areas where external high-frequency influences disturb pulse transmissions. It is used for permanently flexible applications in machine and tool construction, in robotics and on permanently moving machine parts for continuous use in multi-shift opera-tions. With free movement, without tensile stress and without forced motion control capabilities, this cable has proven their reliable performance in drag chain applications. This highly flexible cable with gliding PP core insulation and cut-resistant low adhesive PUR outer sheath, guarantees an optimum service life and very high economic efficiency.
Features
- Cores stranded in layers with optimally matched lay lengths
- Fleece wrapping over each stranding layer, from 4 mm² without fleece wrapping
- Use in drag chains
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 18 | |
| Colour | gray | |
| Core colour sequence | black | |
| Core insulation material | PP | |
| Temperature range (active) | -30 °C to 80 °C | |
| Drag chain suitable | Yes | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| Cable cross-section | 1.0 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Number of cores | 4 | |
| Outer diameter | 11.1 mm | |
| Material | PUR | |
| Test voltage | 3 kV | |
| Product type | control line | |
| Protective conductor available | Yes | |
| Rated voltage U0 | 300 V | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Conductor category | CL.6 = finest stranded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
