3279370001 | Raychem
Heatshrink tubing, 3:1, (44.9/27.9 mm), yellow
Order No.: 39P9316
EAN: 4099891277239
MPN:
3279370001
TMS-SCE-2-2.0-4
Unit Price (€ / mtr.)
5.2241 € *
Available: 0 mtr.
Leadtime: On Request **
Heat shrink tubing, CGPT-R-12.7-0, Raychem
CGPT-R-12.7-0 is a tough, flexible, general purpose polyolefin tubing with good resistance to common fluids and solvents and a high dielectric strength. Its unique blend of chemical, electrical, and physical properties makes it suitable for a wide range of applications, including electrical insulation, strain relief, cable bundling, colorcoding and identification of wires, cables, pipes, and electrical and electronic components, and mechanical protection.
Features
- 2:1 and 3:1 Shrink ratio
- Very good chemical and solvent resistance
- Flexible
- Excellent physical and electrical performance
- RoHS compliant
Technical specifications
| Colour | yellow | |
| Inner diameter after shrinkage | 27.9 mm | |
| Inner diameter before shrinkage | 44.9 mm | |
| contains glue inside | No | |
| Length | 50 mm | |
| max. operating temperature | 135 °C | |
| min. operating temperature | -55 °C | |
| Shrinking rate | 3:1 |
Download
Logistics
| Country of origin | TH |
| Customs tariff number | 39173200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
